LTO-TOSHIBA Series
Battery Packs
AMPHERR Battery Pack LTO Series
For Extreme Durability
AMPHERR Battery Pack LTO-Toshiba Series for Off-Highway Equipment, Commercial Vehicles and applications like Fuel-Cell, Serial Hybrid and Ultra-Fast-Charge.
System Features
- ECE R100.2, ECE R10.6 and UN38.3 (in progress) certifications
- Lloyd's Register certification for marine applications
- IATF 16949:2016-Certified Manufacturing
- Common PJB (Pack Junction Box) for all products
- Efficient liquid cooling system
- CANBus 2.0A-B communication protocol
- Integrated BMS (Battery Management System)
- Integrated precharge circuit and isolation measurement
Specifications
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Subject | Unit | 13kWh - LTO | 15 kWh - LTO | 27kWh - LTO | 31 kWh - LTO | 31kWh - LTO | 36kWh - LTO |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:50 | Battery Pack | LTO-700-013 | LTO-700-015 | LTO-700-027 | LTO-700-031 | LTO-800-031 | LTO-800-036 | |
| 2 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Electrical Specifications | |||||||
| 3 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Installed Energy @1/3C | kWh | 13.2 | 15.2 | 26.5 | 30.5 | 30.9 | 35.6 |
| 4 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Energy Density @1/3C | Wh/kg | up to 50 | up to 56 | up to 55 | up to 62 | up to 56 | up to 64 |
| 5 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Capacity @1/3C | Ah | 20 | 23 | 40 | 46 | 40 | 46 |
| 6 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Nominal Voltage | V | 662 | 662 | 662 | 662 | 773 | 773 |
| 7 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | OCV Range @ 10-90% SoC | V | 608 - 711 | 588 - 713 | 608 - 711 | 588 - 713 | 712 - 837 | 712 - 837 |
| 8 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Min-Max Voltage Range | V | 432 - 778 | 432 - 778 | 432 - 778 | 432 - 778 | 504 - 908 | 504 - 908 |
| 9 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Cont. Charge Current @ 25°C, SoC dependent, step charge | A | 140 | 100 | 280 | 200 | 280 | 200 |
| 10 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Peak Charge Current @ 10s, 25°C, SoC dependent | A | 377 | 377 | 377 | 377 | 324 | 324 |
| 11 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Cont. Discharge Current @ 25°C, SoC dependent | A | 140 | 100 | 280 | 200 | 280 | 200 |
| 12 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Peak Discharge Current @ 10s, 25°C, SoC dependent | A | 377 | 377 | 377 | 377 | 324 | 324 |
| 13 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Cycle Life (based on user power profile, DoD and temp.) | cycle | > 20000 | > 20000 | > 20000 | > 20000 | > 20000 | > 20000 |
| 14 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Communication Protocol | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | |
| 15 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Supply Voltage for Control Equipment | V | Dec-24 | Dec-24 | Dec-24 | Dec-24 | Dec-24 | Dec-24 |
| 16 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Mechanical Specifications | |||||||
| 17 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Cooling Type | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | |
| 18 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Flow Rate | l/min | Oct-15 | Oct-15 | Oct-15 | Oct-15 | Oct-15 | Oct-15 |
| 19 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Pressure Drop @10I/min and 25°C | mbar | < 300 | < 300 | < 300 | < 300 | < 300 | < 300 |
| 20 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Coolant Operating Pressure | bar | < 2 | < 2 | < 2 | < 2 | < 2 | < 2 |
| 21 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Operating Temperature @discharge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| 22 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Operating Temperature @charge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| 23 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Recommended Operating Temperature | °C | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 |
| 24 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Storage Temperature | °C | -40 ~ 60 | -40 ~ 55 | -40 ~ 60 | -40 ~ 55 | -40 ~ 60 | -40 ~ 60 |
| 25 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | IP Rating (when the plug connectors are mated) | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 | |
| 26 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Physical Specifications | |||||||
| 27 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | 2V16 Housing Type | Weight kg |
280 | 280 | ||||
| 28 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Dimensions mm |
960x690x285 | 960x690x285 | |||||
| 29 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | 2V32 Housing Type | Weight kg |
480 | 490 | ||||
| 30 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Dimensions mm |
1710x690x285 | 1710x690x285 | |||||
| 31 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | 2V34 Housing Type | Weight kg |
550 | 560 | ||||
| 32 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Dimensions mm |
1990x690x285 | 1990x690x285 | |||||
| 33 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | 4V16 Housing Type | Weight kg |
500 | 510 | ||||
| 34 | Marketing | 02.09.2026 11:44 | Marketing | 02.09.2026 11:44 | Dimensions mm |
960x690x570 | 960x690x570 |
| 13kWh - LTO | 15kWh - LTO | 27kWh - LTO | 31kWh - LTO | 31kWh - LTO | 36kWh - LTO | ||
| LTO-700-013 | LTO-700-015 | LTO-700-027 | LTO-700-031 | LTO-800-031 | LTO-800-036 | ||
| Electrical Specifications | |||||||
| Installed Energy @1/3C | kWh | 13,2 | 15,2 | 26,5 | 30,5 | 30,9 | 35,6 |
| Energy Density @1/3C | Wh/kg | up to 50 | up to 56 | up to 55 | up to 62 | up to 56 | up to 64 |
| Capacity @1/3C | Ah | 20 | 23 | 40 | 46 | 40 | 46 |
| Nominal Voltage | V | 662 | 662 | 662 | 662 | 773 | 773 |
| OCV Range @ 10-90% SoC | V | 608 - 711 | 588 - 713 | 608 - 711 | 588 - 713 | 712 - 837 | 712 - 837 |
| Min-Max Voltage Range | V | 432 - 778 | 432 - 778 | 432 - 778 | 432 - 778 | 504 - 908 | 504 - 908 |
| Cont. Charge Current @ 25°C, SoC dependent, step charge | A | 140 | 100 | 280 | 200 | 280 | 200 |
| Peak Charge Current @ 10s, 25°C, SoC dependent | A | 377 | 377 | 377 | 377 | 324 | 324 |
| Cont. Discharge Current @ 25°C, SoC dependent | A | 140 | 100 | 280 | 200 | 280 | 200 |
| Peak Discharge Current @ 10s, 25°C, SoC dependent | A | 377 | 377 | 377 | 377 | 324 | 324 |
| Cycle Life (based on user power profile, DoD and temp.) | cycle | > 20000 | > 20000 | > 20000 | > 20000 | > 20000 | > 20000 |
| Communication Protocol | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | |
| Supply Voltage for Control Equipment | V | 12/24 | 12/24 | 12/24 | 12/24 | 12/24 | 12/24 |
| Mechanical Specifications | |||||||
| Cooling Type | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | |
| Flow Rate | l/min | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 |
| Pressure Drop @10I/min and 25°C | mbar | < 300 | < 300 | < 300 | < 300 | < 300 | < 300 |
| Coolant Operating Pressure | bar | < 2 | < 2 | < 2 | < 2 | < 2 | < 2 |
| Operating Temperature @discharge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| Operating Temperature @charge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| Recommended Operating Temperature | °C | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 |
| Storage Temperature | °C | -40 ~ 60 | -40 ~ 55 | -40 ~ 60 | -40 ~ 55 | -40 ~ 60 | -40 ~ 60 |
| IP Rating (when the plug connectors are mated) | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 | |
| Physical Specifications | |||||||
|
2V16 Housing Type |
Weight kg |
280 | 280 | ||||
|
Dimension mm |
960x690x285 | 960x690x285 | |||||
|
2V32 Housing Type |
Weight kg |
480 | 490 | ||||
|
Dimension mm |
1710x690x285 | 1710x690x285 | |||||
|
2V34 Housing Type |
Weight kg |
550 | 560 | ||||
|
Dimension mm |
1990x690x285 | 1990x690x285 | |||||
|
4V16 Housing Type |
Weight kg |
500 | 510 | ||||
|
Dimension mm |
960x690x570 | 960x690x570 |
Need Technical Support? We are here to help!
Get a Quote!
AMPHERR Battery Systems LTO
The AMPHERR Batteries LTO Series / LTO-TOSHIBA deliver reliable power and stable performance for a wide range of industrial and stationary energy applications. Based on advanced lithium titanate (LTO) technology, these systems are designed to meet demanding requirements for efficiency, durability, and safety.With ultra-fast charging capability, exceptional cycle life, and outstanding performance in extreme temperatures, the LTO Series is ideally suited for mission-critical applications requiring maximum uptime and long-term reliability.
- Lithium-titanate technology for:
- Ultra-fast charging
- Long cycle life
- High safety and temperature stability
Ideal for heavy-duty and high-utilization use cases
- Light Commercials
- Citybuses
- Locomotives
- Container
- Marine
- Industrial
- Trucks
- Tractor
