400V SERIES
Battery Packs
AMPHERR Battery Pack 400V-Series
Power for Industrial Demand
AMPHERR Battery Pack 400V-Series, high-voltage lithium-ion batteries for Off-Highway Equipment, Marine (Lloyd's Register Certified), GenSet, Railway, Commercial Vehicles, Buses.
System Features
- ECE R100.3, ECE R10.6 and UN38.3 certifications
- Lloyd's Register certification for marine applications
- IATF 16949:2016-Certified Manufacturing
- Common PJB (Pack Junction Box) for all products
- Efficient liquid cooling system
CANBus 2.0A-B communication protocol - Integrated BMS (Battery Management System)
- Integrated precharge circuit and isolation measurement
Specifications
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Subject | Unit | 42kWh - NMC | 63kWh - NMC | 63kWh - NMC (LR) | 52kWh - LFP |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 16:44 | Battery Pack | NMC-400-042 | NMC-400-063 | NMC-400-063X |
LFP-400-052 | |
| 2 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Electrical Specifications | |||||
| 3 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Installed Energy @1/3C | kWh | 42.1 | 63,4 | 63,4 | 52.2 |
| 4 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Energy Density @1/3C | Wh/kg | up to 148 | up to 174 | up to 174 | up to 117 |
| 5 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Capacity @1/3C | Ah | 117 | 177 | 177 | 135 |
| 6 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Nominal Voltage | V | 353 | 351 | 351 | 384 |
| 7 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | OCV Range @ 5-95% SoC | V | 334 - 409 | 334 - 406 | 334 - 406 | 357 - 425 |
| 8 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Min-Max Voltage Range | V | 269 - 422 | 269 - 418 | 269 - 418 | 300 - 438 |
| 9 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Cont. Charge Current @ 25°C, SoC dependent, step charge | A | 200 | 209 | 209 | 135 |
| 10 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Peak Charge Current @ 10s, 25°C, SoC dependent | A | 399 | 348 | 348 | 270 |
| 11 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Cont. Discharge Current @ 25°C, SoC dependent | A | 228 | 174 | 174 | 135 |
| 12 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Peak Discharge Current @ 10s, 25°C, SoC dependent | A | 500 | 500 | 500 | 473 |
| 13 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Cycle Life @ 90%DoD, 0.5C/ 0.5C | cycle | up to 3000 | up to 4000 | up to 4000 | up to 4000 |
| 14 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Communication Protocol | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | |
| 15 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Supply Voltage for Control Equipment | V | 12/24 | 12/24 | 12/24 | 12/24 |
| 16 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Mechanical Specifications | |||||
| 17 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Cooling Type | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | |
| 18 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Flow Rate | l/min | 10-15 | 10-15 | 10-15 | 10-15 |
| 19 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Pressure Drop @10I/min and 25°C | mbar | < 300 | < 300 | < 300 | < 300 |
| 20 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Coolant Operating Pressure | bar | < 2 | < 2 | < 2 | < 2 |
| 21 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Operating Temperature @discharge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| 22 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Operating Temperature @charge | °C | -20 ~ 55 | -20 ~ 55 | -20 ~ 55 | 0 ~ 55 |
| 23 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Recommended Operating Temperature | °C | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 |
| 24 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Storage Temperature | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -20 ~ 55 |
| 25 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | IP Rating (when the plug connectors are mated) | IP67 | IP67 | IP67 | IP67 | |
| 26 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Physical Specifications | |||||
| 27 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 1F24 Housing Type - Weight | kg | 370 | |||
| 28 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 1660x1000x145 | |||
| 29 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 1F30 Housing Type - Weight | kg | 460 | |||
| 30 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 2050x1000x145 | |||
| 31 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 2H16 Housing Type - Weight | kg | 490 | |||
| 32 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 2075x600x285 | |||
| 33 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 2V16 Housing Type - Weight | kg | 280 | |||
| 34 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 960x690x285 | |||
| 35 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 2V24 Housing Type - Weight | kg | 390 | 390 | ||
| 36 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 1330x690x285 | 1330x690x285 | ||
| 37 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 2V32 Housing Type - Weight | kg | 480 | |||
| 38 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 1710x690x285 | |||
| 39 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 3V16 Housing Type - Weight | kg | 400 | |||
| 40 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 960x690x428 | |||
| 41 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | 4V16 Housing Type - Weight | kg | 500 | |||
| 42 | Marketing | 03.09.2026 14:22 | Marketing | 03.09.2026 14:22 | Dimensions (LxWxH) | mm | 960x690x570 |
| 42kWh - NMC | 63kWh - NMC | 63kWh - NMC | 52kWh - LFP | ||
| Battery Pack | NMC-400-042 | NMC-400-063 | NMC-400-063X | LFP-400-052 | |
|
|
|||||
| Electrical Specifications | |||||
| Installed Energy @1/3C | kWh | 42,1 | 63,4 | 63,4 | 52,2 |
| Energy Density @1/3C | Wh/kg | up to 148 | up to 174 | up to 174 | up to 117 |
| Capacity @1/3C | Ah | 117 | 177 | 177 | 135 |
| Nominal Voltage | V | 353 | 351 | 351 | 384 |
| OCV Range @ 5-95% SoC | V | 334 - 409 | 334 - 406 | 334 - 406 | 357 - 425 |
| Min-Max Voltage Range | V | 269 - 422 | 269 - 418 | 269 - 418 | 300 - 438 |
| Cont. Charge Current @ 25°C, SoC dependent, step charge | A | 200 | 209 | 209 | 135 |
| Peak Charge Current @ 10s, 25°C, SoC dependent | A | 399 | 348 | 348 | 270 |
| Cont. Discharge Current @ 25°C, SoC dependent | A | 228 | 174 | 174 | 135 |
| Peak Discharge Current @ 10s, 25°C, SoC dependent | A | 500 | 500 | 500 | 473 |
| Cycle Life @ 90%DoD, 0.5C/ 0.5C | cycle | up to 3000 | up to 4000 | up to 4000 | up to 4000 |
| Communication Protocol | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | |
| Supply Voltage for Control Equipment | V | 12/24 | 12/24 | 12/24 | 12/24 |
| Mechanical Specifications | |||||
| Cooling Type | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | |
| Flow Rate | l/min | 10-15 | 10-15 | 10-15 | 10-15 |
| Pressure Drop @10I/min and 25°C | mbar | < 300 | < 300 | < 300 | < 300 |
| Coolant Operating Pressure | bar | < 2 | < 2 | < 2 | < 2 |
| Operating Temperature @discharge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| Operating Temperature @charge | °C | -20 ~ 55 | -20 ~ 55 | -20 ~ 55 | 0 ~ 55 |
| Recommended Operating Temperature | °C | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 |
| Storage Temperature | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -20 ~ 55 |
| IP Rating (when the plug connectors are mated) | IP67 | IP67 | IP67 | IP67 | |
| Physical Specifications | |||||
|
1F24 Housing Type |
Weight kg |
370 | |||
|
Dimensions mm |
1660x1000x145 | ||||
|
1F30 Housing Type |
Weight kg |
460 | |||
|
Dimension mm |
2050x1000x145 | ||||
|
2H16 Housing Type |
Weight kg |
490 | |||
|
Dimensions mm |
2075x600x285 | ||||
|
2V16 Housing Type |
Weight kg |
280 | |||
|
Dimension mm |
960x690x285 | ||||
|
2V24 Housing Type |
Weight kg |
390 | 390 | ||
|
Dimensions mm |
1330x690x285 | 1330x690x285 | |||
|
2V32 Housing Type |
Weight kg |
480 | |||
|
Dimension mm |
1710x690x285 | ||||
|
3V16 Housing Type |
Weight kg |
400 | |||
|
Dimensions mm |
960x690x428 | ||||
|
4V16 Housing Type |
Weight kg |
500 | |||
|
Dimension mm |
960x690x570 |
Get a Quote!
Need Technical Support? We are here to help!
AMPHERR Battery Systems 400V
The AMPHERR Batteries 400V provide dependable power and consistent performance for a wide range of applications. Designed for efficiency, long service life, and operational safety, they offer a reliable energy solution for industrial systems and stationary power needs with an advanced high-voltage lithium-ion system. Their modular and scalable platform architecture enables flexible integration, helping manufacturers reduce development effort while ensuring long-term compatibility with future system requirements.
- Proven solution for automotive and industrial applications
- Balanced performance, efficiency, and scalability
- Widely compatible with existing infrastructures
- Light Commercials
- Citybuses
- Locomotives
- Container
- Marine
- Industrial
- Trucks
- Tractor
