800V SERIES
Battery Packs
AMPHERR Battery Pack 800V-Series
Ultra-High Power for Next-Generation Systems
AMPHERR Battery Pack 800V-Series, high-voltage lithium-ion batteries for Off-Highway Equipment, Marine (Lloyd's Register Certified), GenSet, Railway, Commercial Vehicles, Buses.
System Features
- ECE R100.3, ECE R10.6 and UN38.3 certifications
- Lloyd's Register certification for marine applications
- IATF 16949:2016-Certified Manufacturing
- Common PJB (Pack Junction Box) for all products
- Efficient liquid cooling system
CANBus 2.0A-B communication protocol - Integrated BMS (Battery Management System)
- Integrated precharge circuit and isolation measurement
Specifications
| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | Subject | Unit | 42kWh - NMC | 84kWh - NMC | 127kWh - NMC | 127kWh - NMC (LR) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:42 | Battery Pack | NMC-800-042 | NMC-800-084 | NMC-800-127 | NMC-800-127X |
|
| 2 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Electrical Specifications | |||||
| 3 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Installed Energy @1/3C | kWh | 42.3 | 84.2 | 126,8 | 126,8 |
| 4 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Energy Density @1/3C | Wh/kg | up to 148 | up to 176 | up to 179 | up to 179 |
| 5 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Capacity @1/3C | Ah | 59 | 117 | 177 | 177 |
| 6 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Nominal Voltage | V | 705 | 707 | 703 | 703 |
| 7 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | OCV Range @ 5-95% SoC | V | 665 - 814 | 668 - 818 | 667 - 812 | 667 - 812 |
| 8 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Min-Max Voltage Range | V | 528 - 835 | 538 - 845 | 538 - 835 | 538 - 835 |
| 9 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Cont. Charge Current @ 25°C, SoC dependent, step charge | A | 70 | 200 | 209 | 209 |
| 10 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Peak Charge Current @ 10s, 25°C, SoC dependent | A | 174 | 354 | 348 | 348 |
| 11 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Cont. Discharge Current @ 25°C, SoC dependent | A | 58 | 228 | 174 | 174 |
| 12 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Peak Discharge Current @ 10s, 25°C, SoC dependent | A | 355 | 354 | 356 | 356 |
| 13 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Cycle Life @ 90%DoD, 0.5C/ 0.5C | cycle | up to 3000 | up to 3000 | up to 4000 | up to 4000 |
| 14 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Communication Protocol | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | |
| 15 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Supply Voltage for Control Equipment | V | 12/24 | 12/24 | 12/24 | 12/24 |
| 16 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Mechanical Specifications | |||||
| 17 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Cooling Type | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | |
| 18 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Flow Rate | l/min | 10-15 | 10-15 | 10-15 | 10-15 |
| 19 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Pressure Drop @10I/min and 25°C | mbar | < 300 | < 300 | < 300 | < 300 |
| 20 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Coolant Operating Pressure | bar | < 2 | < 2 | < 2 | < 2 |
| 21 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Operating Temperature @discharge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| 22 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Operating Temperature @charge | °C | -20 ~ 55 | -20 ~ 55 | -20 ~ 55 | -20 ~ 55 |
| 23 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Recommended Operating Temperature | °C | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 |
| 24 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Storage Temperature | °C | -30 ~ 55 | -20 ~ 45 | -30 ~ 55 | -30 ~ 55 |
| 25 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | IP Rating (when the plug connectors are mated) | IP67 | IP67 | IP67 | IP67 | |
| 26 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Physical Specifications | |||||
| 27 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 1F32 Housing Type | Weight kg |
490 | |||
| 28 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
2215x1000x145 | ||||
| 29 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 2V16 Housing Type | Weight kg |
280 | |||
| 30 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
960x690x285 | ||||
| 31 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 2H16 Housing Type | Weight kg |
520 | |||
| 32 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
2075x600x285 | ||||
| 33 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 2F24 Housing Type | Weight kg |
730 | |||
| 34 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
1660x1000x285 | ||||
| 35 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 2V32 Housing Type | Weight kg |
510 | |||
| 36 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
1710x690x285 | ||||
| 37 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 3V32 Housing Type | Weight kg |
750 | 750 | ||
| 38 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
1710x690x428 | 1710x690x428 | |||
| 39 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 3H16 Housing Type | Weight kg |
760 | 760 | ||
| 40 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
2075x600x428 | 2075x600x428 | |||
| 41 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 4V16 Housing Type | Weight kg |
530 | |||
| 42 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
960x690x570 | ||||
| 43 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 4V24 Housing Type | Weight kg |
760 | |||
| 44 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
1330x690x570 | ||||
| 45 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | 5L48 Housing Type | Weight kg |
780 | |||
| 46 | Marketing | 02.09.2026 11:26 | Marketing | 02.09.2026 11:26 | Dimensions mm |
1090x790x713 |
| 42kWh - NMC | 84kWh - NMC | 127kWh - NMC | 127kWh - NMC | ||
| Battery Pack | NMC-800-042 | NMC-800-084 | NMC-800-127 | NMC-800-127X | |
|
|
|||||
| Electrical Specifications | |||||
| Installed Energy @1/3C | kWh | 42,3 | 84,2 | 126,8 | 126,8 |
| Energy Density @1/3C | Wh/kg | up to 148 | up to 176 | up to 179 | up to 179 |
| Capacity @1/3C | Ah | 59 | 117 | 177 | 177 |
| Nominal Voltage | V | 705 | 707 | 703 | 703 |
| OCV Range @ 5-95% SoC | V | 665 - 814 | 668 - 818 | 667 - 812 | 667 - 812 |
| Min-Max Voltage Range | V | 528 - 835 | 538 - 845 | 538 - 835 | 538 - 835 |
| Cont. Charge Current @ 25°C, SoC dependent, step charge | A | 70 | 200 | 209 | 209 |
| Peak Charge Current @ 10s, 25°C, SoC dependent | A | 174 | 354 | 348 | 348 |
| Cont. Discharge Current @ 25°C, SoC dependent | A | 58 | 228 | 174 | 174 |
| Peak Discharge Current @ 10s, 25°C, SoC dependent | A | 355 | 354 | 356 | 356 |
| Cycle Life @ 90%DoD, 0.5C/ 0.5C | cycle | up to 3000 | up to 3000 | up to 4000 | up to 4000 |
| Communication Protocol | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | CANBus 2.0A-B | |
| Supply Voltage for Control Equipment | V | 12/24 | 12/24 | 12/24 | 12/24 |
| Mechanical Specifications | |||||
| Cooling Type | Liquid Cooling | Liquid Cooling | Liquid Cooling | Liquid Cooling | |
| Flow Rate | l/min | 10-15 | 10-15 | 10-15 | 10-15 |
| Pressure Drop @10I/min and 25°C | mbar | < 300 | < 300 | < 300 | < 300 |
| Coolant Operating Pressure | bar | < 2 | < 2 | < 2 | < 2 |
| Operating Temperature @discharge | °C | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 | -30 ~ 55 |
| Operating Temperature @charge | °C | -20 ~ 55 | -20 ~ 55 | -20 ~ 55 | -20 ~ 55 |
| Recommended Operating Temperature | °C | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 | 15 ~ 35 |
| Storage Temperature | °C | -30 ~ 55 | -20 ~ 45 | -30 ~ 55 | -30 ~ 55 |
| IP Rating (when the plug connectors are mated) | IP67 | IP67 | IP67 | IP67 | |
| Physical Specifications | |||||
|
1F32 Housing Type |
Weight kg |
490 | |||
|
Dimension mm |
2215x1000x145 | ||||
|
2V16 Housing Type |
Weight kg |
280 | |||
|
Dimension mm |
960x690x285 | ||||
|
2H16 Housing Type |
Weight kg |
520 | |||
|
Dimension mm |
2075x600x285 | ||||
|
2F24 Housing Type |
Weight kg |
730 | |||
|
Dimension mm |
1660x1000x285 | ||||
|
2V32 Housing Type |
Weight kg |
510 | |||
|
Dimension mm |
1710x690x285 | ||||
|
3V32 Housing Type |
Weight kg |
750 | 750 | ||
|
Dimension mm |
1710x690x428 | 1710x690x428 | |||
|
3H16 Housing Type |
Weight kg |
760 | 760 | ||
|
Dimension mm |
2075x600x428 | 2075x600x428 | |||
|
4V16 Housing Type |
Weight kg |
530 | |||
|
Dimension mm |
960x690x570 | ||||
|
4V24 Housing Type |
Weight kg |
760 | |||
|
Dimension mm |
1330x690x570 | ||||
|
5L48 Housing Type |
Weight kg |
780 | |||
|
Dimension mm |
1090x790x713 |
Get a Quote!
Need Technical Support? We are here to help!
AMPHERR Battery Systems 800V
The AMPHERR Batteries 800V deliver high-performance power and exceptional efficiency for next-generation applications. Designed for maximum energy output, long service life, and advanced safety, they provide a reliable solution for high-voltage industrial systems and modern electric mobility platforms. Their scalable architecture and standardized interfaces simplify system integration while supporting fast charging, reduced development time, and future-ready electrification strategies.
- Ultra-fast charging capability
- Maximum efficiency and reduced system losses
- Designed for premium e-mobility and high-end applications
- Light Commercials
- Citybuses
- Locomotives
- Container
- Marine
- Industrial
- Trucks
- Tractor
