AMPHERR IS THE NEW DEFINITION OF CURRENT IN THE WORLD OF ELECTROMOBILITY. WITH OUR NEW PRODUCT LINEUP, YOU WILL FIND THE BEST FIT FOR EVERY USE CASE AND OUR STANDARD BATTERY PACKS, YOU CAN HAVE A MATCHING SOLUTION WITHIN AS SHORT AS 8 WEEKS.
ACCESORIES
SUPPORTED VEHICLES
citybus
trucks
industral
marine
locomotive
BATTERY PACK SPECIFICATIONS
| SYSTEM SPECIFICATIONS | VALUE | UNIT |
| NUMBER OF DEVICES | up to 6 | |
| COMMUNICATION PROTOCOL | CANBus 2.0A-B, Ethernet (RJ45), Wi-Fi | |
| INGRESS PROTECTION | IP54 | |
| SUPPLY VOLTAGE | 12 / 24 | V |
| DIMENSIONS | 485x365x146 | mm |
| WEIGHT | 10 | kg |
SYSTEM FEATURES
- System connection of up to 6 devices (Battery or PDU)
- Compact structure
- Remote monitoring of entire system
- Over-the-air software update capability for all system components
- CAN 2.0A-B system communication
- Ethernet or Wi-Fi external communication
- Confi gurable voltage supply
- Short-range, mid-range and medium cycle applications
- Freely scalable and robust structure
- Common PJB (Power Junction Box) for all products
- Effi cient liquid cooling system
- Integrated Battery Management System
- Integrated precharge circuit and isolation measurement
- Compatible design according to ECE R100.2, ECER R10 and UN38.3 — possible
- Compatible design according to ISO 26262 up to ASIL C — possible
DOWNLOADS DOCUMENT
- Brochure (PDF)
SUPPORTED EVs
LIGHT COMMERCIALS
citybusES
locomotive
CONTANIER
marine
industral
trucks
trACTOR
BATTERY PACK LAYOUT
MULTIPLE BATTERY SYSTEM
